VLDF-F139DAWS-300LPT840 / 0532546
Product Description
Light strip from the VLDF product family. Optical control via , beam pattern symmetric, , light emission . Lamp LED-M installed, Replacement by specialist. The luminaire generates a rated luminous flux of 2775 lm in light colour 840, luminous flux adjustable: stepless. The long LED service life enables long use with consistent lighting quality. High quality of light thanks to a standard colour tolerance of < 3 SDCM. Housing made of , white, protection rating IP20. Suitable for direct mounting on normally flammable materials. Simple, cost-effective one-man mounting with screws through the keyholes in the upper part of the luminaire or with flexible fixing spacing using fixing clips (accessories). Fixing kits are available for pendant mounting, see accessories. With electronic electrical component DALI. Replacement by specialist. Rated voltage 220 - 240 V AC/DC 50 - 60 Hz.
Order Information
| Item number | 0532546 |
| GTIN | 4029299471137 |
General
| Product category | Light strip |
| Range of application | Education | Office | Retail | Industry |
Dimensions
| Dimension L | 888 mm |
| Dimension B | 36 mm |
| Dimension H | 65 mm |
| Dimension A1 | 600 mm |
| Dimension A4 | 166 mm |
| Dimension K | 25 mm |
| Dimension K1 | 25 mm |
| Dimension K2 | |
| Net weight | 1.240 kg |
Mounting
| Mounting type | Attachment |
Housing
| Colour | white |
| Protection class | IP20 |
| Glow-wire test | 650 °C |
Electrical version
| Type of control | DALI |
| Nominal voltage | 220–240 V, 0/50–60 Hz |
| Rated power | 19.0 W |
| Protection class | I |
Lighting technology
| Light emission | |
| Light distribution | symmetric |
| Rated luminous flux | 2775 lm |
| Luminaire efficiency | 146 lm/W |
Light source
| Lamp | LED-M |
| Lamp included | Yes |
| Colour rendering index Ra | ≥ 80 |
| Colour temperature | 4000 K |
| Colour location tolerance (SDCM) | < 3 SDCM |
Download Center
Approvals:
| Item number - Designation | Produktbeschreibung | Download | Wishlist |
0202596 -
VLDHK
|
Chain fixing for VLD, lengthw. adjustment, 1 pc |
|
|
0202597 -
VLDHW
|
Wall fixing for VLD, lengthw. adj, white, 1 pc |
|
|
|
0202597SI -
VLDHW-SI
|
Wall fixing for VLD, lengthw. adj., silver 1 pc |
|
|
0202592 -
VLDHSD
|
Wire pendant VLD w. ceiling fixing, lengthw. adj. 1 pc |
|
|
0204003 -
ZRO RAHMENÖFFNER
|
Tool for easy opening of the light frame |
|
|
