VL2MF-S500-7-OF-DA2-SIL | 2500086

Sensor module for RIDI LINIA EVO for the VL2TM mounting rail system, DALI-2 / Silvair design Master. Gear tray made from extruded aluminium profile, traffic white, similar to RAL 9016. Sensor made from polycarbonate, UV-stabilised. Simply clip on for electrical contact and mechanical fastening in the system-based RIDI LINIA EVO DIN rail system. Colour and optical coding for easy mounting. Mechanical coding to prevent incorrect installation (polarity reversal protection). Rated voltage 220 - 240 V AC 50 - 60 Hz. Electrical adapter for flexible connection through wiring in trunking. Colour-coded and optically coded for easy mounting. With light and motion detector. Detection range crosswise Ø 7,4 m, detection field 41 m². Daylight-dependent presence detection with adjustable daylight, threshold and setpoint values, as well as an adjustable base light level and adjustable hold-up times. Setup and configuration via the Silvair app. The detection field can be extended by networking with the corresponding extension sensors. Can be networked with other Silvair control elements on the same network. DALI-2 broadcast output signal for controlling up to 30 DALI gear trays.

Compatibility of different APCON components only guaranteed within the respective APCON system: APCON EASY / EASY BLE / INDIVIDUAL / UNLIMITED.

These luminaires comply with the stipulations of the Food Hygiene Act as defined by Regulation (EC) No. 852/2004 (HACCP) Annex II Chapter I section 2 a, b, Chapter II section 1c relating to luminaires.

They are suitable for use in food production areas without the use of high-pressure cleaners.
